# 插入元素

# 方法原型

void InsertElement(string elementSaveInfoCollection);

注意：此 API 例外，不遵循公共的 JSON 参数和回调返回。即：

不能用 WebToolParamModel 来包装参数，参数是裸的字符串
无法获取到方法的执行结果

# 参数

string elementSaveInfoCollection

这是一个 XML 字符串。是唯一确定一个元素的存储对象。

一个例子如下：

<ElementCollection>
  <Elements>
    <Picture>
      <PictureName>test-svg24.svg</PictureName>
      <Alpha>1</Alpha>
      <Bright>0</Bright>
      <Contrast>0</Contrast>
      <Saturation>0</Saturation>
      <DisplayRegion>
        <Rectangle>0,0,200,200</Rectangle>
      </DisplayRegion>
      <Style>
        <StyleType>None</StyleType>
        <PicturePresetStyle>None</PicturePresetStyle>
      </Style>
      <MetaData>
        <PictureSize>200,200</PictureSize>
        <FileSize>8532</FileSize>
      </MetaData>
      <Id>146a4a61-872f-4be1-97d3-1cc75c54b862</Id>
      <X>540</X>
      <Y>260</Y>
      <Width>200</Width>
      <Height>200</Height>
      <Rotation>0</Rotation>
      <IsLocked>False</IsLocked>
      <CanClone>False</CanClone>
      <HasMask>False</HasMask>
      <IsErasable>False</IsErasable>
      <IsErased>False</IsErased>
      <RotateOrigin>0.5,0.5</RotateOrigin>
    </Picture>
  </Elements>
</ElementCollection>

其中，除 Source 支持资源类型外，其他与希沃白板 enbx 的存储格式完全相同。

注意： 凡元素存储数据中涉及到资源的，都必须以 id:// 开头，随后紧跟 Data URL 作为实际数据。

# 如何得知元素/元素集的 XML 存储数据

在希沃白板中制作一个元素；
选中并复制此元素；
查看剪贴板，得知复制所得的存储数据文件路径；
去对应的文件路径中查看元素的存储数据。

剪贴板查看器

# 调用示例

InsertElement 方法可以给插件带来完全创建可交互式课件内容的能力。

window.external.InvokeMethod(
  `{
    "method":"InsertElement",
    "args":
    }`)
